DT-52-EN/SW-75/20 WiFi Curtain Motor
DT-52-EN/SW-75/20 WiFi Curtain Motor - Image 2

DT-52-EN/SW-75/20 WiFi Curtain Motor

Feature Specification
Model DT-52-EN/SW-75/20
Rated Input Power 75 W
Open/Close Speed 20 cm/sec
Safety Curtain Weight 100 kg
Voltage 230 V
Rated Current 0.34 A
Running Time 4 Minutes
Maximum Revolutions Infinite
Number of Wires 3
Protection Class IP20
Length 254 mm
Built-In WiFi Yes
Built-In Receiver Yes
Remote Available with Extra Charges

Original price was: ₹8,500.00.Current price is: ₹7,500.00.

Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,
Call Us
Whatsapp Us

The DT-52-EN/SW-75/20 Curtain Motor is a high-performance automation solution engineered for modern smart curtain systems.

With 75W rated input power and a smooth operating speed of 20 cm per second, this motor ensures efficient and silent curtain movement. It supports curtains up to 100 kg, making it ideal for heavy residential and commercial installations.

Equipped with built-in WiFi and integrated receiver, the motor enables direct smartphone control without requiring external modules. It also supports remote operation (remote available at extra charges).

Featuring an electronic limit system with auto limit setting, the motor automatically detects and sets open/close positions. The manual override and touch start function allow users to operate curtains simply by pulling the fabric.

Additional integration is supported through dry contact input, making it suitable for smart home automation systems.

Designed for durability, this motor operates on 230V, uses 3-wire connectivity, and offers infinite revolution range for flexible installation.

🔹 KEY FEATURES

  • Built-In WiFi Connectivity

  • Integrated Receiver

  • Electronic Limit System

  • Auto Limit Setting

  • Manual Override

  • CAT 6 Input

  • Smartphone Control

  • Long Lifetime & Durable Performance

  • Heavy-Duty 100kg Capacity
