The DM-45-SL-10-26 Tubular Motor is a high-performance automation solution engineered for larger and heavier curtain or roller blind installations.

Built with a 50 mm tube diameter, this motor delivers 10 Nm rated torque at 26 RPM, ensuring strong and efficient operation for systems up to 35 kg load capacity. It supports installations with a maximum width of 6 meters and maximum height of 6 meters, making it suitable for large residential and commercial applications.

With a running noise level of 37 dB, it maintains quiet and smooth performance.

This model features a 4-wire wired configuration and does not include an in-built receiver, making it ideal for integration with external wall switches, controllers, or centralized automation systems.

Its compact 575 mm overall length (L1) allows efficient installation while maintaining heavy-duty capability.

🔹 KEY FEATURES

• High Torque 10 Nm Output

• Smooth 26 RPM Operation

• Heavy-Duty 50mm Tube Design

• 4-Wire Wired Control System

• No In-Built Receiver (External Control Required)

• Supports Up to 35 Kg Load

• Suitable for Wide Systems up to 6m

• Maximum 45 Limit Turns

• Reliable & Durable Performance
